Ürün ayrıntıları:
|
| Günlük kapasite: | 3000kg/gün | Taşıma yöntemi: | Mikrobiyal Fermentasyon |
|---|---|---|---|
| Malzeme: | SUS304 paslanmaz çelik, Q235 karbon çeliği | Ortam sıcaklığı: | -10~40°C |
| Kabin Sıcaklığı: | 45-75°C | Güç: | 37kw |
| Gerilim: | 380V 50HZ (Özelleştirilebilir) | Enerji tüketimi: | 1kg başına ≤ 0,25kWh |
| Azaltma Oranı: | % 90 | Hizmet ömrü: | ≥10 yıl |
| Ağırlık: | 4500kg | Boyutlar: | 5800mm*2170mm*2430mm |
| Isıtma sistemi: | Otomatik sabit sıcaklık kontrolü | Karıştırma Sistemi: | Aşırı yük korumalı otomatik karıştırma |
| Deodorasyon Sistemi: | Sprey koku giderme | ||
| Vurgulamak: | 24-hour rapid composting Organic Waste Composting Machine,380V 50Hz Bio Waste Composting Unit,37kW power Organic Waste Converter |
||
| Brand | TOGO |
|---|---|
| Model | TG-CC-3000 |
| Daily Capacity | 3000kg/d |
| Handling Method | Microbial Fermentation |
| Function | Lifting system, microbial aerobic fermentation, deodorization, PLC automatic control system |
| Material | The cabin and parts in contact with materials are made of corrosion-resistant materials or treated with anti-corrosion technology. The material of the parts in contact with garbage is SUS304 stainless steel, and other supporting materials are made of Q235 carbon steel with baking varnish. |
| Ambient temperature (℃) | -10～40 |
| Running system | Fully automatic PLC control, with automatic induction stop device, anti-jamming function, fault alarm; with automatic feeding. |
| Heating system | Automatic constant temperature control heating is adopted. The temperature range of the cabin heating system can be adjusted and set as needed, and it has an overheating protection device. |
| Mixing system | Automatic stirring, the stirring system of the machine room can be adjusted and set as needed. The main stirring motor should have an overload protection device and have manual, automatic operation and discharging functions. |
| Deodorization system | Spray deodorization system, no odor is generated after treatment |
| Complete electrical system |
|
| Energy consumption | Power consumption per 1kg of material processed ≤ 0.25kWh |
| Feeding method | Automatic feeding |
| Service life (years) | ≥10 years |
| Reduction Rate | 90% |
| Ambient Temperature | 45-75°C |
| Power | 37kw |
| Voltage | 380V 50HZ (Customizable) |
| Final Product | Organic Fertilizer |
| Size | 5800mm*2170mm*2430mm |
| Weight | 4500kg |
The kitchen waste is crushed and put into the fermentation bin. It is quickly decomposed under the action of high-temperature composite bacteria (65℃~75℃) and intermittent stirring. The macromolecular organic matter is converted into harmless substances such as CO₂ and H₂O. The waste gas is purified by the deodorization system and discharged. There is no secondary pollution in the whole process. The reduction rate reaches 85%-90% within 24 hours, and the final output is about 10% of organic fertilizer substrate.
The organic fertilizer is rich in beneficial bacteria such as Bacillus and organic matter, which can be directly used to improve soil and improve fertilizer efficiency. It has the dual benefits of increasing production and improving quality and reducing agricultural emissions, realizing the resource utilization of garbage.
Wuxi TOGO Environment Equipment Co., Ltd. is committed to the adjustment solutions of harmless, resource-based and reduced-volume treatment equipment for organic waste such as kitchen waste, kitchen waste, fruits and vegetables, and landscaping.
The company has successfully developed the sixth generation of distributed kitchen waste treatment equipment and has independently developed more than 50 products with more than 60 national patents. The company has passed ISO9001, ISO1401, ISO45001 three-system certification, intellectual property management system certification, and EU CE certification.
In 2022, the company participated in the compilation of the national standard "Equipment for the Treatment and Utilization of Kitchen Waste in the Catering Industry" and became the first company in Wuxi to establish a carbon management system. In 2023, the company was awarded the "High-tech Enterprise Certificate". In 2024, the company won the first prize of Gansu Province's Excellent Engineering Survey and Design.
You can leave us a message and we will reply to every message in time. Or we can contact us through the website: www.togohb.com/www.togocomposter.com/www.togosolution.com. And you can also find our contact information on contact page.
The lead time is usually 30 days, if in stock we can ship within 1 week.
Our usual payment terms are 30% deposit and the balance before shipment based on the video and photos of the machine. Letter of Credit (L/C) is also acceptable. Trade terms such as EXW, FOB, CFR, CIF, DDU, etc. are also applicable.
We are a factory with 100% pre-delivery video inspection to ensure quality. And as a gold supplier on Alibaba, Alibaba provides guarantee services.
1) Our warranty period is one year, and we provide lifetime technical service.
2) We provide free factory operation and maintenance training.
3) We will provide some vulnerable parts of the equipment to ensure normal operation.
4) If any quality problems occur during the warranty period, TOGO will provide full tracking service.
5) We provide online video service within 24 hours for warranty issues.
6) For major issues outside warranty, we provide online video service within 48 hours.
